HMDA series is designed for low profile type with low RDC & ultra large current. Its molded magnetic shielded type is suitable for high-density mounting and ultra low buzz noise. Soldering conditions can be easily confirmed when mounting onto the board. It also provides customers, with embossed carrier type packaging for automatic mounting machine.
Features:
* RoHS compliant * Low profile type * Shielded construction * Ultra low buzz noise due to molding construction
Applications:
* High density DC/DC converters * POL converters * High current VRM/VRD for notebook / Server / desktop CPUs * High speed charger * For thickness less than 1.2mm, suitable for low profile applications eg: Ultra thin NB/Monitor/TV/Tablet
Send Message
Preview on Mobile
X
Wechat scan code or copy link mobile phone open
X
Copy the link
HMDA Series SMD Power Inductors
HMDA Series
0.00~0.00
SMD power indcutors with molding type-HMDA series, full specifications, applications for high density DC/DC converters, POL converters, High current VRM/VRD for notebook, Server, desktop CPUs and more.
