HWHF Series Wire Wound Chip Inductor

HWHC Series, Due to accurate wire winding technology, these chip inductors are designed for filtering, impedance matching, resonance and choke circuits for RF designer. Both standard series custom designs are available.

Features:

* Can be used for high frequency bands up to GHz and stable inductance at high frequency.
* The high self resonant frequency realizes high Q value.
* Resin-coated surface enables excellent mounting.
* Low DC resistance design is ideal for low loss.
* High output and low power consumption.

Applications:

* For higfh-requency applications including mobile phones,portable phones.
* Base Station.
* Wireless LAN/ mouse/ keyboard/ earphone
* Bluetooth.
* Repeater.
* Remote control.
